| 主要技術參數 | TECHNICAL DATA | UNIT | YP6209 |
| 最大(da)壓制力 | Max.Pressing Force | kN | 62000 |
| 最大頂(ding)出力 | Max.Ejecting Force | kN | 275 |
| 動(dong)梁最大行(xing)程 | Max.Plunger Stroke | mm | 215 |
| 動(dong)梁(liang)下平面與(yu)工(gong)作臺面最小間距 | Min.Distance between Press Plunger and Table | mm | 510 |
| 動梁下平(ping)面與工作(zuo)臺面最大間距 | Max.Distance between Press Plunger and Table | mm | 725 |
| 左右立(li)柱間凈空 | Clearance between Columns | mm | 1950 |
| 動梁工作面前(qian)后寬(kuan)度 | Useful Width of Plunger | mm | 1220 |
| 工(gong)作臺面前(qian)后寬度 | Width of Press Table | mm | 1400 |
| 最大填料深度(du) | Max.Filling Depth | mm | 70 |
| 空(kong)循環次數可達 | Working Cycles in idle Stroke | mm-1 | 16 |
| 周(zhou)期(qi)中(zhong)加(jia)壓次(ci)數 | Strokes Per Cycle | times | 2～5 |
| 主電機功率(lv) | Power of the Main Motor | kW | 160 |
| 系統(tong)裝(zhuang)油(you)量 | System Oil Capacity | L | 1750 |
| 系統耗氣量 | Air Consumption | m3/h | 0.4 |
| 常(chang)溫水流量 | Water Consumption at 24℃ | m3/h | 20 |
| 主機重(zhong)量 | Weight of the Press Body | t | 133 |
